ABS/HIPS Single/Multi-layer Plate Extrusion Line

ABS/HIPS Single/Multi-layer Plate Extrusion Line

This production line can produce 4 kinds of industrial board for different application purpose: 1)ABS、HIPS/GPPS Refrigerator board.

Send Inquiry

Description

Property

This ABS sheet production line can produce 4 kinds of industrial board for different application purpose: 1)ABS,HIPS/GPPS Refrigerator board. These board is used for refrigerator door and inner gallbladder, drawers, water dispensers, etc. 2) ABS/PMMA sanitary plate. Mainly for the field of bath products, such as the bathtub, the shower cabinet, the vapor room, washing bowl, etc. 3) ABS/PC Baggage plate. Mainly applied in the field of draw-bar boxers, luggage cases, recreation bags, etc. 4) ABS,ABS+PC car plate: mainly used in to produce tops of cars and buses, instrument boards, backrest, car doors, window frames, shells of the motorcycles, golf vehicles, etc.

Specialty

JWELL is the major supplier in China refrigerator industry on ABS\HIPS/GPPS refrigerator board extrusion line. Clients such as Haier, Media etc choose to cooperate with JWELL mainly. JWELL ABS sheet production line is quite popular with clients domestic and abroad.

Technical Parameters

Model	JW 120/70/60-2200	JW120/60/45-1800	JW 160/60-2200
Material	ABS, PMMA	ABS,PS,HIPS	ABS, PS,HIPS
Extrusion specification	Φ120/38,70/35,60/35	Φ120/38,60/35,45/35	Φ160/38,60/35
Co-extrusion layer	A/B/C/B/A	A/B/C	A/B, A/B/A
Product width	A/B/C/B/A 2200mm	1800mm	2200mm
Thickness of the product	2-8mm	1-6mm	1-6mm
Capacity (Max.)	600KG/H	500Kg/h	1200kg/h

Process

Electric control system→Loading and drying system→Single screw extruder→ Hydraulic Screen changer, melt pump→T-die→Feedblock → Three-roller calender → Cooling bracket →Roller temperature controller →Haul off unit→Protective film lamination unit → Gilluotine→Belt conveyer
